Ambiance – Illusion 47

The Illusion® 47 Linear Gas Fireplace comes standard with – matte black interior finish, the Ecotel programmable thermostatic remote and gorgeous Vancouver Island drift wood logs. You can enhance the look of your Illusion® 47 to fit your home. You have the option to upgrade the exterior look with – Decorative Front. Also, optional logs are offered in oak or white birch. At last, double the flames by adding the porcelain enameled reflective panels inside the firebox. Enjoy its cozy flame and look anytime!

Technical Details
Power
 NG MAX
24 000 BTU		 NG MIN
17 000 BTU		 LP MAX
24 000 BTU		 LP MIN
17 000 BTU
Fuel Management
 Valve Type
IPI		 Thermostat
Remote Control		 Turn Down
29%NG / 29%LP
Dimensions
 GLASS
40 1⁄2” x 16 3⁄4” (678 sq in)		 FRAMMING
47 3⁄8” W x 18 9⁄16” D x 39 3⁄8” H		 OVERALL
46 7⁄8” W x 18 13⁄16” D x 39 1⁄16” H
Mantel Shelf Clearances
 Combustible Mantel Shelf
6-inch Shelf: 16″		 Ambiance® Non-Combustible Mantels
No Clearance required
Venting
 TYPE
Direct Vent		 MAX HEIGHT
40 Feet		 INSIDE & OUTSIDE DIAMETERS
4″ & 7″
Optional Blower
 Type
Variable Speed		 CFM
100
401-203-2876 Shop More Financing

Product Request Quote Form

This field is hidden when viewing the form
Name(Required)
Project Type
Project Timeline
Are you also interested in:
Drop files here or
Max. file size: 2 MB.
    Please take photo from floor to ceiling.
    Drop files here or
    Max. file size: 2 MB.

      Power
      		 NG MAX
      24 000 BTU      		 NG MIN
      17 000 BTU      		 LP MAX
      24 000 BTU      		 LP MIN
      17 000 BTU
      Fuel Management
      		 Valve Type
      IPI      		 Thermostat
      Remote Control      		 Turn Down
      29%NG / 29%LP
      Dimensions
      		 GLASS
      40 1⁄2" x 16 3⁄4" (678 sq in)      		 FRAMMING
      47 3⁄8" W x 18 9⁄16" D x 39 3⁄8" H      		 OVERALL
      46 7⁄8" W x 18 13⁄16" D x 39 1⁄16" H
      Mantel Shelf Clearances
      		 Combustible Mantel Shelf
      6-inch Shelf: 16"      		 Ambiance® Non-Combustible Mantels
      No Clearance required
      Venting
      		 TYPE
      Direct Vent      		 MAX HEIGHT
      40 Feet      		 INSIDE & OUTSIDE DIAMETERS
      4" & 7"
      Optional Blower
      		 Type
      Variable Speed      		 CFM
      100

      Additional information

      Brand

      Ambiance
      Fuel Type

      Gas
      Product Type

      Fireplace
      Design Style

      Linear
