FS-520-F-1300x485-K
FS2052020F20BP20prod20120Main
Jotul International – FS 520 F
Technical Details

    Specifications

  • Height
    1685 mm

  • Width
    800 mm

  • Depth
    540 mm

  • Weight

    183 kg

  • Log size
    up to 50 cm

  • Flue outlet

    Ø 150 mm

  • Flue exit options

    Top /
    Rear

  • Nom output

    7.0 kW

  • Efficiency

    77 %

  • CO Emission

    0.07 %

  • Dust Product Emission

    14 mg/Nm³

  • NOx Emission

    54 mg/Nm³

  • OGC Emission

    60 mg/Nm³

  • Closed combustion

    Yes

  • Clean burn

    Yes

  • External air intake

    Yes

401-203-2876 Shop More Financing

Product Request Quote Form

This field is hidden when viewing the form
Name(Required)
Project Type
Project Timeline
Are you also interested in:
Drop files here or
Max. file size: 2 MB.
    Please take photo from floor to ceiling.
    Drop files here or
    Max. file size: 2 MB.

        Specifications

      • Height
        1685 mm

      • Width
        800 mm

      • Depth
        540 mm

      • Weight

        183 kg

      • Log size
        up to 50 cm

      • Flue outlet

        Ø 150 mm

      • Flue exit options

        Top /
        Rear

      • Nom output

        7.0 kW

      • Efficiency

        77 %

      • CO Emission

        0.07 %

      • Dust Product Emission

        14 mg/Nm³

      • NOx Emission

        54 mg/Nm³

      • OGC Emission

        60 mg/Nm³

      • Closed combustion

        Yes

      • Clean burn

        Yes

      • External air intake

        Yes

      Additional information

      Brand

      Jotul International
      Product Type

      Fireplace
      Fuel Type

      Wood
